Customisation & Manufacturing Services
Our BS EN ISO 9001:2008 certified workshop facilitates engineered bearing solutions, with standard product customised to meet exact client requirements, avoiding long manufacturers lead times.
Services available:
| » |
Diametrical clearances – C3/C4/C5 to 500mm bore. |
| » |
Lubrication features – W33, W22, W26, and W513 to 1000 mm bore. |
| » |
Bore shaft modification – K, K30, non standard shafts to 500mm bore. |
| » |
Locating slots – N1, N2, VE variations. |
| » |
Face pairing and pre-loading – BG, CA, CB, CC, GA, GB, GC, UA, UO variations. |
| » |
Enlargement of standard bore sizes and reductions of OD’s. |
| » |
Precision Spacers – taper roller bearing sets DF or DB variations to 500mm O.D. |
| » |
Spacer ring production – for imperial taper roller assemblies. |
| » |
New inner/outer ring manufacture – C1, C2 and all special radial internal clearances. |
| » |
Non standard inner ring production – NUB, NJP and NUP designs to 500mm bore. |
| » |
Angle ring production – HJ series both E and non E types. |
| » |
Special coatings – aluminium oxide coating of surfaces for electrical resistance. |
| » |
Cage manufacture – steel and brass material. |
| » |
Hybrid ceramic bearing production. |
| » |
Preload modification – light to medium, medium to heavy. |
| » |
‘U’ and ‘V’ grooves – for wire carrying. |
| » |
Rolling bearing maintenance and reconditioning. |
Special Manufacturing services:
Manufacture of non standard, obsolete, special ball and roller bearings certified to BS EN ISO 9001:2008.
Back up roll bearing production.
Bearings manufactured to customers drawings and bespoke requirements.
Special sleeve and nut manufacture – adaptor, withdrawal, hydraulic, European and USA specifications to 1000mm bore, nuts to 1200mm O.D. |
|
